Fimco - F1006 - 1006-L 1" 6 Zone Plastic Valve

Fimco - F1006 - 1006-L 1" 6 Zone Plastic Valve

by Fimco
SKU F1006
$ 66.07 - $ 66.07
$ 66.07
$ 66.07 - $ 66.07
$ 66.07

Install Manual

The model #1006 Hydro Indexing Valve has one 1" inlet and six 1" outlets which are all slip fit. This valve is recommended for use in a city water driven irrigation system and can run from 2 to 6 zones based on the chosen cam configuration (selected above). Other available options listed above are:

• The standard flow stem and disc assembly requires a minimum of 10GPM, the low-flow stem and disc assembly requires a minimum of only 6GPM.
• The optional Zone Indicator can come pre-installed and is a very handy device. It is extremely useful when working on or troubleshooting an irrigation system.
• In order for this valve to run 3 or 4 active zones you must purchase the special white cam (available as an option here). The black 3 or 4 zone cam is not compatible with this valve.


• The standard flow stem and disc assembly requires a minimum of 10GPM, the low-flow stem and disc assembly requires a minimum of only 6GPM.
• The optional Zone Indicator can come pre-installed and is a very handy device. It is extremely useful when working on or troubleshooting an irrigation system.
• In order for this valve to run 3 or 4 active zones you must purchase the special white cam (available as an option here). The black 3 or 4 zone cam is not compatible with this valve.
