Kichler - 330165MWH - 52" Patio Ceiling Fan Matte White

Spec Sheet

The Renew Patio 52 inch Ceiling Fan in a Matte White finish easily integrates across multiple applications and décor with its soft, modern design aesthetics

• Perfect for outdoor areas such as covered patios or pergolas
• Comes with reversible blades for design flexibility
• Features a pull chain design for easy 3-speed adjustments
• Offering a step up from a standard ceiling fan motor for improved air performance
• No visible vents in motor housing for a clean look
• Clean lined style blades are reversible - letting you choose between a Matte White or a Distressed Antique Gray finish
• Powerful AC motor offers superior air movement. Plus, AC motors are versatile as they pair to a variety of optional accessories, including wall and handheld remotes
• Ideal for any covered, outdoor area that's 100-150 sq ft, such as covered patios and pergolas
• Adjust the installation of your ceiling fan by utilizing optional downrods to suit varying ceiling heights
• Mounts two ways - close to the ceiling as a hugger for lower ceilings that have a minimum of 7' clearance, or extended down from the ceiling utilizing downrods for taller ceilings
• Coordinates well with brown, silver, gold, or black based hardware and accessories. This Renew fan fits nicely with bright pops or a muted color palette.
• Equipped with a switch on the motor housing to give you the ability to change the fan rotation direction to suit your seasonal needs
• To clean, simply wipe with damp cloth

What's in the box?

• (5) 52" Plywood Fan blades, (1) 4.5"Downrod, (1) 153mmx18mm AC Motor, (1) Mounting Kit, (1) Hanger System, (1) Handheld Control System

Airflow:

• CFM (High): 4581
• CFM (Low): 2086
• RPM (High): 142
• RPM (Low): 64

Blade Finish & Specs:

• Blade Finish 1: Matte White
• Blade Finish 2: Dist Antiq Gray
• Blade Material: PLYW

• Blade Pitch: 12
• Blade Sweep: 52
• Blades Reversible: Yes
• Number of Blades: 5


Certifications/Qualifications:

• Title 20 Compliant: Yes

Dimensions:

• Downrod 1: 1.00 x 4.5"
• Downrod 2: Dual Mount
• Base Backplate: 6.50 DIA

• Weight: 17.20 LBS

• Height: 13.50"

Electrical:

• Amps (High): 0.50
• Amps (Low): 0.23
• Motor Size: 153 x 18

• Motor Type: AC Induction
• Input Voltage: 120.00 V

Housing:

• Fan Primary Control System: Pull Chain

• Primary Material: Steel


Light Source:

• Watts (High): 59

• Watts (Low): 13

Mounting/Installation:

• Direct Wire: Yes
• Interior/Exterior: Exterior

• Lead Wire Length: 78"
• Location Rating: Damp
• Mounting Style: Downrod
• Mounting Weight: 14.80 LBS
• Wire Connectors: Wire Nuts

Product/Ordering Information:

• Finish: Matte White
